HK Audio L5-LTS - HK AUDIO LTS SYSTEM

Enlarge ↗

❮❯

sites/dagexpress/products/Yorkville/thumbnails_60_60/HK-Audio-L5-LTS.jpg

sites/dagexpress/products/Yorkville/thumbnails_60_60/HK-Audio-L5-LTS-1.jpg

sites/dagexpress/products/Yorkville/thumbnails_60_60/HK-Audio-L5-LTS-2.jpg

sites/dagexpress/products/Yorkville/thumbnails_60_60/HK-Audio-L5-LTS-3.jpg

Brand	HK Audio ›
Price:	$ 1599.00

DESCRIPTION

In the past, only large line arrays have been capable of projecting the entire frequency spectrum powerfully over 30 m and beyond – until now. For the first time, the LINEAR 5 LTS brings true long-throw characteristics to an ultra-compact format. For you as the user, this means that you’ll need fewer speaker components, thus saving valuable truck space. It also makes rigging and ground stacking much easier and faster. This makes the new LINEAR 5 Long-Throw-System LTS not only the simplest, but also the most economical solution to achieve the best sound results for small to medium-sized live and corporate events as well as installation projects.

Technical data
Power-handling nominal (RMS) 600 W
Power-handling, program 1200 W
Frequency response +/-3 dB 108 Hz - 14 kHz
Frequency response -10 dB 100 Hz - 20 kHz
Sensitivity 1 W @ 1 m 110 dB half space
Max. SPL @ 10% THD 133 dB half space (100 Hz – 12 kHz average)
Max. SPL Peak @ 10% THD 138 dB half space
Electrical impedance 8 ohms
Protective circuits PTC circuit
Low-/mid speaker 3x 8", 2" voice coil
HF Driver 1", 1.75" voice coil
Directivity 60° x +5°/-25° MCT horn
Crossover frequency 1.7 kHz, 12 dB/Oct.
Connections 2x Speakon NL4, pin assignment switch
Pole mount MonoTilt 0°
Rigging points 5x M8 (AP-8)
Carrying handles 2x MultiGrip
Housing Birch multiplex
Finish Black acrylic enamel
Front grille 2 mm metal grille backed with black acoustic foam
Dimensions (WxHxD) 44 x 68 x 46.1 cm 17-5/16 x 26-25/32 x 18-5/32"
Weight 26.4 kg / 58.2 lbs
